3.0 mm Pitch 2 Pole 24 Pin Wire to Wire Connectors
Product Details:
3.0 mm Pitch 2 Pole 24 Pin Wire to Wire Connectors Price And Quantity
- 100000-200000 Piece
3.0 mm Pitch 2 Pole 24 Pin Wire to Wire Connectors Trade Information
- 1 Week
Product Description
For the past 17 years, we have been serving our respected clients by manufacturing and supplying excellent quality 3.0 mm Pitch 2 Pole 24 Pin Wire to Wire Connectors. These are well engineered and fabricated at our ultra modern facility using top notch quality materials that we procure from reliable sources only. Offered products are extensively used for connecting wires to wires in safe and hassle free manner. We offer alluring discounts to our regular clients or those who purchase these 3.0 mm Pitch 2 Pole 24 Pin Wire to Wire Connectors in bulk. We are able to deliver our products in a promised time frame.
Specifications
Pitch | 3.0mm |
No. of Poles | 2 - 24 Pin |
Current rating | 5.0A AC/DC |
Voltage rating | 250 V AC/DC |
Contact resistance | 10m ohm.max |
Insulation resistance | 1000M ohm.Min |
Withstanding voltage | 1500V AC for one minute |
Operating temperature range | - 25°C to + 105°C |
Material and Finish
Insulator | High Temp.Plastic (UL94V-0) |
Contact | Phosphor Bronze |
Plating | Tin Plated |
